Created with Pixso. 12 Fiber MPO/APC Singlemode Fiber Loopback Module for QSFP testing

12 Fiber MPO/APC Singlemode Fiber Loopback Module for QSFP testing

Marka Adı: GoreLink
Model Numarası: G4431
Adedi: 1 adet
Teslim Zamanı: 1-3 İş Günü
Ödeme Şartları: Banka havalesi, Western Union, PayPal
Ayrıntılı Bilgiler
Menşe yeri:
Çin
Ürün:
MPO SM Fiber optik geri döngü modülü
Özellik:
Yüksek hızlı optik ağ testi için uygundur
Parça NO.:
GL-MLB-12SMF
Bağlayıcı Türü:
MPO/APC Dişi
Elyaf türü:
Teker
Renk:
Yeşil
Ekleme Kaybı:
≤0.35dB
Çalışma Sıcaklığı:
-20~+75°C
Depolama Sıcaklığı:
-40~+85°C
Ambalaj bilgileri:
1 adet/torba
Vurgulamak:

12 fiber MPO/APC loopback module

,

single mode fiber loopback for QSFP

,

MPO/APC fiber testing tool

Ürün Tanımı
12 Fiber MPO/APC Singlemode Fiber Loopback Module for QSFP Testing
Overview
The MPO Fiber Loopback Module is engineered for comprehensive fiber optic network testing, signal routing, and transceiver verification in high-speed communication systems. This essential testing tool is widely deployed in data centers, telecommunication networks, and optical transmission systems to validate signal continuity and assess network performance.
Featuring high-quality MPO/MTP connectors and precision fiber alignment, this loopback module delivers stable optical performance with minimal insertion loss. It serves as an ideal solution for 40G/100G optical transceiver testing, switch verification, and comprehensive network diagnostics.
Applications
  • Data center cabling systems
  • 40G/100G transceiver testing
  • QSFP module verification
  • Optical switch testing
  • Telecom networks
  • Fiber optic diagnostics and maintenance
Key Features
  • MPO/MTP connector interface
  • Low insertion loss and stable performance
  • High-density fiber connectivity
  • Compact and durable design
  • Plug-and-play installation
  • Suitable for high-speed optical network testing
Technical Specifications
Fiber Loopback Type MPO loopback
Fiber Structure 12F
Fiber Mode Singlemode
Polish Type APC
Insertion Loss ≤0.35dB
Fiber Connector Female
Housing Color Green
Compliance Telcordia GR-326-CORE
12 Fiber MPO/APC Singlemode Fiber Loopback Module for QSFP testing 0
Documentation
Download Datasheet
Ordering Information
Part Number Description
GL-MLB-12SMF 12F SM MPO Loopback, Standard loss, Female
For further assistance, please contact us at sales@gorelink.com
